Product Parameters
| Specifications | ||
| Nominal Voltage | 12V | |
| Capacity(25) | 10HR(10.8V) | 100 Ah |
| 5HR(10.5V) | 87.5 Ah | |
| 1HR(9.60V) | 62 Ah | |
| Dimension | Length | 330±2mm(13.0inch) |
| Width | 171±2mm(6.73inch) | |
| Height | 214±2mm(8.19inch) | |
| Total Height | F5: 220±2mm(8.66inch) | |
| T9: 224±2mm(8.81inch) | ||
| Approx. Weight | 28.6kg(63.0lbs)±4% | |
| Terminal type | F5/T9 | |
| Internal resistance(Fully charged, 25℃) | Approx. 5.8m Ω | |
| Capacity affected by temperature (10HR) |
40℃ 25℃ 0℃ -15℃ |
102% 100% 85% 65% |
| Self-discharge(25℃) | 3 month 6 month 12 month |
Remaining Capacity: 91% Remaining Capacity: 82% Remaining Capacity: 65% |
| Nominal operating temperature | 25℃±3℃(77℉±5℉) | |
| Operating | Discharge Charge |
-15℃~50℃(5°F~122°F) -10℃~50℃(14°F~122°F) |
| temperature range | Storage | -20℃~50℃(-4F~122℉) |
| Float charging voltage(25℃) | 13.50 to 13.80VTemperature compensation:-18mV/℃ |
|
| Cyclic charging voltage(25℃) | 14.50 to 14.80VTemperature compensation:-30mV/℃ |
|
| Maximum charging current | 30A | |
| Terminal material | Copper | |
| Maximum discharge current | 1000A(5 sec.) | |
| Designed floating life(20℃) | 10years | |
| Constant Current Discharge Characteristics (A, 25℃) | |||||
| F.V/TIME | 10min | 15min | 30min | 60min | 90min |
| 9.60V | 315 | 248 | 150 | 93.0 | 69.0 |
| 9.90V | 306 | 242 | 147 | 91.6 | 68.6 |
| 10.2V | 293 | 233 | 143 | 89.3 | 68.0 |
| 10.5V | 280 | 225 | 139 | 87.5 | 66.9 |
| 10.8V | 265 | 213 | 134 | 84.8 | 66.2 |
| Constant Current Discharge Characteristics (A, 25℃) | ||||||
| F.V/TIME | 2h | 3h | 5h | 8h | 10h | 20h |
| 9.60V | 54.8 | 38.3 | 26.8 | 18.4 | 15.3 | 8.02 |
| 9.90V | 54.5 | 38.0 | 26.6 | 18.3 | 15.2 | 8.00 |
| 10.2V | 54.0 | 37.8 | 26.4 | 18.1 | 15.2 | 7.98 |
| 10.5V | 53.2 | 37.5 | 26.3 | 18.0 | 15.1 | 7.93 |
| 10.8V | 51.8 | 36.4 | 25.5 | 17.5 | 15.0 | 7.88 |
| Constant Power Discharge Characteristics (Watt, 25℃) | |||||
| F.V/TIME | 10min | 15min | 30min | 60min | 90min |
| 9.60V | 3402 | 2718 | 1683 | 1060 | 787 |
| 9.90V | 3300 | 2652 | 1649 | 1044 | 782 |
| 10.2V | 3164 | 2554 | 1599 | 1018 | 775 |
| 10.5V | 3028 | 2468 | 1560 | 998 | 763 |
| 10.8V | 2858 | 2337 | 1503 | 967 | 755 |
| Constant Power Discharge Characteristics (Watt, 25℃) | ||||||
| F.V/TIME | 2h | 3h | 5h | 8h | 10h | 20h |
| 9.60V | 635 | 450 | 316 | 218 | 182 | 96.2 |
| 9.90V | 631 | 447 | 315 | 217 | 182 | 96.0 |
| 10.2V | 625 | 444 | 312 | 215 | 181 | 95.7 |
| 10.5V | 616 | 441 | 310 | 214 | 180 | 95.2 |
| 10.8V | 600 | 428 | 301 | 207 | 179 | 94.5 |
Product Description
The 100Ah-12V Gel Battery for Solar System, model PST-100Ah-12V-6FM, a premium choice for PV System Batteries. Specially formulated for solar energy storage, this battery ensures reliable and efficient power supply in various solar installations.
The PST-100Ah-12V-6FM boasts a nominal voltage of 12V and a substantial capacity of 100 Ah at a 10-hour rate, making it ideal for extensive solar power applications. Its dimensions of 330±2mm in length, 171±2mm in width, and 214±2mm in height, combined with a weight of approximately 28.6kg, offer a balance of performance and portability.
The internal resistance of this battery is approximately 5.8mΩ when fully charged, facilitating smooth energy transfer. It maintains its capacity effectively across varying temperatures, with minimal performance loss even in extreme conditions. The self-discharge rate is low, preserving up to 91% of capacity after three months and 82% after six months at 25°C.
Engineered for solar systems, the PST-100Ah-12V-6FM supports fast charging and high discharge currents, with a maximum charging current of 30A and a maximum discharge current of 1000A for five seconds. The float charging voltage ranges from 13.50 to 13.80V, with temperature compensation, while the cyclic charging voltage is between 14.50 and 14.80V.
Designed for long-term reliability, this battery offers a floating life of 10 years. The copper terminals ensure superior conductivity, minimizing energy loss. With an operating temperature range of -15°C to 50°C for discharge and -10°C to 50°C for charge, and a storage temperature range of -20°C to 50°C, the PST-100Ah-12V-6FM is versatile and robust.
In summary, the 100Ah-12V Gel Battery for Solar System, model PST-100Ah-12V-6FM, is a superior choice for PV System Batteries, offering high performance, durability, and reliability. It is the perfect solution for storing and distributing solar energy efficiently.
Warehouse photos
