Your Professional High Mast Lighting Pole Supplier
Panailo Smart Technology company limited established in 2020, is a professional company specializing in the research, development, sales and service of solar street lights, also including LED lamps, batteries, lighting poles, and solar power systems and so on.
-
![High Mast Flood Light Poles]()
High Mast Flood Light Poles·High-strength steel: Excellent load-bearing capacity for outdoor scenarios·Corrosion-resistant: Hot-dip galvanized surface, anti-rust for 20+ years·Customizable: Flexible height/diameter to matchread more -
![18m High Mast Lighting Pole]()
18m High Mast Lighting Pole·High-strength steel: Excellent load-bearing capacity for outdoor scenarios·Corrosion-resistant: Hot-dip galvanized surface, anti-rust for 20+ years·Customizable: Flexible height/diameter to matchread more
Why Choose us
Comprehensive Product Qualifications
Our company has established a robust qualification framework. In terms of management systems, we are certified under ISO 9001 for quality management, ISO 14001 for environmental management, and ISO 45001 for occupational health and safety management.
Professional Expertise
Our company is supported by a dedicated research and development team specializing in the innovative application of photovoltaic energy storage and intelligent lighting technologies. This expertise ensures that our products maintain an industry-leading position in terms of light conversion efficiency, battery longevity, and automated control systems.
Global Strength and Reach
Thousands of homes and businesses worldwide are using Panailo's full range of products and cost-effective solutions to power their homes, facilities, streets, and squares.
Parameter
|
Warranty(Year): 10-Year |
Lighting solutions service: Auto CAD layout |
|
Luminous Efficacy(Im/w):150 |
Material: Q235B |
|
Place of Origin: Jiangsu, China |
Brand Name: PANAILO |
|
Material: Steel, Hot roll galvanizing |
Type: Polygonal, Round or octangon |
|
Application: Square,Highway;airport;road |
Name: Hot Dip Galvanized 18M High Mast Lighting Poles |
|
Surface treatment: Hot dip galvanized |
Height:18M |
|
Thickness: 4 mm (negative tolerance) |
Powder coated: White;blue;silver;grey |
|
Wind speed:160 Km/h |
Quality Control: ISO9001:2000 |
Benefits of High Mast Lighting Pole
Cost-effective
Since most high mast lighting poles use LED lights, it increases their longevity, and the process also ensures that the generated voltage degrades slowly and gradually. This helps extend the LED lights’ lifespan, making them cost and energy efficient. High mast lightings use lamps or halogens of high wattage, which reduces electricity bills.
Lighting performance
High lighting levels offer maximum coverage. This is one of the crucial benefits of high mast light poles, as they do not emit heat or infrared light. They also consume less electricity, thus making them energy efficient. The multi-point design of the high ly distributes light in different directions.
Environmentally friendly
Previously used HID lamps for high mast light poles were not environmentally friendly due to the generation of high-pressure sodium, mercury vapor, and metal halides. However, high mast LED lighting systems are free of any toxic gasses, thus making them harmless for the users and environment.
Durability
LEDs in high mast lighting pole lighting make them an excellent investment for corporate solutions, mostly because the cost and time are saved due to the reduced need for maintenance.
Controlled heat emission
High mast lighting pole lights generate a lot of heat from the floodlights. Also, they are the most potent lighting appliance that contributes to the temperature rising around the location where it is installed. But using LED lights restricts heat emission due to active thermal management.
Highways: Along major arterial roads and highways, the best high mast lighting pole installations provide uniform illumination over long stretches of road, ensuring perfectly safe driving conditions, especially at night for my road.
Intersections: At busy intersections, high-mast lighting improves visibility and reduces the risk of accidents, especially during rush hour or bad weather.
Parking lots: Large parking lots, such as shopping centers and airports, often use tall poles to illuminate the entire area, improving safety for both visitors and vehicles.
Installation Process of High Mast Lighting Pole
Preparing The Mast For Installation
Before the installation of a high mast pole, it is important to check that all accessories are at the erection site or not. Check the pitch circle diameter (PCD) and diameter of the foundation bolts for installation.
The bottom section and the middle section of the pole are laid on the round wooden block. The middle section is then inserted into the bottom section, keeping a distance of 20mm. The chain pulley block is fixed at the base plate of the mast. After that the pulley is fixed with the flange, and the hook is fixed with the top end. After that, all sections are pulled by the chain block.
Mast Head Assembly
The head frame of the High Mast Lighting Pole is fitted with wire ropes and cables inserted inside the mast with the help of a nylon rope. The nylon rope is inserted in the longitudinal section of the pole during the assembly of other sections.
The wire ropes and cables are passed onto the pulleys of the head frame. The pulley is a non-corrodible material that has a self-lubricating brush bearing attached with a stainless steel spindle of a diameter appropriate for rope and cables. When the wire and ropes are passed on the pulley, it is attached to the stopper clamp that is welded on the base section of the mast.
Foundation Bolt Assembly
To ensure the foundation of the poles is right and it does not fall over during harsh weather conditions, it is necessary to have proper foundation assembly. As foundation bolts are important for structural safety, it is critical to check whether or not the bolt threads are greased and cleaned. The nuts are fixed 15mm above the ground at the same height to ensure the nuts are in one place.
Elevation Of Assembly Mast
After assembling each part of the mast carefully and checking the nuts and bolts of the mast, the final step is to elevate the structure above the ground. The center of gravity is determined, and a sling is placed in that position. A straining of rope with shackles is secured with the sling to adjust the crane hook with it. Finally, the assembled mast is lifted.
Electrical System
At the masthead, cables are attached to the lantern carriage. This is fitted with luminaires, a CG box, and a junction box.
Transportation
Whether it is air freight, express delivery, or sea freight, we can arrange shipments according to the time required by customers. We help customers inquire about the best rates and arrange the delivery of your goods in the most economical way. This allows you to control the schedule of the entire project to meet seasonal cargo demand.
Certificate
We're professional high mast lighting pole suppliers in China, specialized in providing high quality customized products. We warmly welcome wholesale discount high mast lighting pole for sale here and get pricelist from our factory. For price consultation, contact us.
